2.9G/CC Acrylate Thermal Heat Transfer Pads , Fiber Optics Thermal Conductive Pad

Product Categories
Shenzhen Aochuan Technology Co., Ltd
Contact Now

2.9G/CC Acrylate Thermal Heat Transfer Pads , Fiber Optics Thermal Conductive Pad

  • 1
  • 2

Brand Name : AOK

Model Number : TP-200SF

Certification : RoHS, Reach, UL

Place of Origin : China

MOQ : 1000pcs

Payment Terms : T/T

Delivery Time : 13-15working days

Packaging Details : 400mmx200mm

Composition : Acrylate

Color : Green

Thickness : 1.0~10.0 (mm)

Density : 2.9(g/cc)

Hardness : 45±5(Shore OO)

Usage Temperature : -40~150（℃）

Breakdown Voltage : ≥6.0（kv/mm）

Flammability : V-1

Thermal conductivity : 2.0±0.1（W/m.K）

Contact Now

0.5mm Thickness Green Silicone Free Thermal Pad For Fiber Optics

Attribute Value Test Method
Composition Acrylate -
Color Green Visual
Thickness(mm) 0.5-10.0 ASTM D374
Density(g/cc) 2.9 ASTM D792
Hardness(shore oo) 45±5 ASTM D2240
Usage Temperature(℃) -40~150 --
Electrical
Breakdown Voltage(kv/mm) ≥6.0 ASTM D149
Flammability V-1 UL94
Thermal
Thermal conductivity(W/m.K) 2.0 ASTM D5470

Product feature
■ Thermal conductivity:2.0,3.0W/m.K
■ Naturally tacky, easing application
■ Silicone free
■ Excellent, high volume applications
■ Excellent electrical isolation
■ Excellent compression vs. deflection performance.


Typical applications
■ Fiber Optics
■ Medical Device
■ Hard Disc Driver
■ Automotive Sensors and Modules
■ Silicon Sensitive Components


Purchase information

Standard size: 200*400mm, which can be die-cut into various sizes and shapes as specified by customers. The increasing gradient of thickness is 0.25mm
